ASTM A580 / A580M
Stainless steel wire
Standard specification for stainless steel wire, including round, flat, shaped and extruded wire.
Stainless Steel — Industrial Product
Stainless Steel Wire 304
Austenitic 304 stainless steel wire supplied to ASTM A580 / EN 10088-3 for springs, mesh, fasteners and industrial applications.
Indicative priceUSD 1,800 - 2,400 / MT
Lead time10 - 20 working days
01
Overview
Stainless Steel Wire 304 combines austenitic stainless steel with 18–20% chromium and 8–10% nickel for reliable general corrosion resistance and consistent dimensional control. The bright annealed surface and uniform mechanical properties make the wire suited to spring production, wire mesh, filters, fasteners, kitchen equipment and chemical processing components. Supplied to ASTM A580 with mill test certification per EN 10204 3.1, it supports global procurement for industrial and sanitary component manufacturing.
Key Characteristics
- 01 Corrosion Resistance Provides improved resistance to corrosive industrial environments.
- 02 Good Formability Supports bending, forming and other fabrication processes with suitable processing conditions.
- 03 Good Weldability Supports welding using suitable procedures and compatible filler materials.
- 04 High Temperature Capability Suitable for elevated-temperature service within the applicable material limits.
- 05 Oxidation Resistance Provides resistance to oxidation and scaling at elevated temperatures.
- 06 Standard Compliance Manufactured and supplied in accordance with the specified material and product standards.
Typical Applications
- Food & Beverage Hygienic process piping and equipment for food, beverage, brewing and dairy production.
- Kitchen & Catering Equipment Worktops, sinks and food-service equipment where cleanliness and environmental durability are required.
- Chemical Processing Process piping, transfer systems and equipment for corrosive and high-purity media.
- Pharmaceutical Hygienic process systems, vessels and manufacturing equipment for pharmaceutical production.
- Springs & Fasteners Springs, bolts, studs, nuts and other mechanical fastening components.
- Electronics & Electrical Conductive, shielding and structural components for electrical and electronic equipment.
- Wire Rope & Cable Hoisting ropes, stay cables and armoured cables for load-bearing and protection applications.
02
Specifications
Numbers in this section correspond to the applicable product standard, formatted for direct use in enquiry and approval documents.
Product specification
- Material
- Austenitic stainless steel
- Grade
- 304 / 1.4301 / SUS304
- UNS designation
- S30400
- Product form
- Wire
- Manufacturing method
- Cold drawn
- Surface / condition
- Mill finish; pickled / polished on request
- Cross-section
- Solid circular section, drawn to fine diameter
Supply specifications
- Diameter
- 0.2 - 12.0 mm
- Tensile grade
- Per applicable standard
- Coil weight
- 5 - 500 kg per coil
- Surface finish
- As-drawn; coated on request
- Packaging
- Spool / coil / cut-to-length
- Marking
- Standard mill marking; customer marking on request
Final supply is confirmed against the project drawing, purchase agreement and the mill test certificate.
Chemical composition
ElementRequirement
C <= 0.08 %
Si <= 0.75 %
Mn <= 2.00 %
P <= 0.045 %
S <= 0.030 %
Cr 18.0 - 20.0 %
Ni 8.0 - 10.5 %
N <= 0.10 %
Fe Balance
Reference: ASTM A580 304.
Mechanical properties
PropertyRequirement
Tensile strength >= 515 MPa
Yield strength (0.2% offset) >= 205 MPa
Elongation in 50 mm >= 40 %
Hardness <= 201 HB / <= 92 HRB
Reference: ASTM A580 304 at room temperature.
Physical properties
PropertyTypical Value
Density 8.0 g/cm³
Elastic modulus 193 GPa
Thermal conductivity 16.3 W/m·K at 100°C
Electrical resistivity 0.72 μΩ·m
Specific heat 500 J/kg·K
Melting range 1,400 - 1,450 °C
Thermal expansion 17.3 x 10⁻⁶ /°C
Reference: Typical material values, 304.
Reference framework
Standards & documentation
The applicable product, dimensional and inspection standards should be confirmed together in the purchase specification.
02
EN 10088-3
Stainless steel wire rod and drawn wire
European reference for stainless steel wire rod and drawn wire for general purposes.
03
JIS G4309
Stainless steel wires
Japanese reference for stainless steel wires for general, spring and welding applications.
04
GB/T 4240
Stainless steel wires
Chinese reference for stainless steel wires for general purposes.
05
ISO 16143-2
Stainless steel wire rod and drawn wire
International reference for stainless steel wire rod and drawn wire.
06
EN 10204
Inspection documents
Defines inspection document types such as 3.1 and 3.2 for metallic product delivery.
03
Capability
From custom dimensions and precision sizing to heat treatment, surface finishing and product-specific processing, Wayland coordinates supply solutions tailored to your requirements.
Cutting
Cut-to-length and custom cutting according to order requirements.
Custom Dimensions
Non-standard dimensions, tolerances and dimensional combinations subject to product and mill capability.
Precision Sizing
Precision sizing and dimensional control for tighter tolerance requirements.
Cold Working
Cold drawing, cold sizing and other cold-working processes where required.
Heat Treatment
Heat treatment according to material, specification and applicable standard.
Surface Finishing
Surface treatment and finishing according to product, specification and application requirements.
Forming
Bending, forming and other shape modification according to drawings or order requirements.
Custom Profiles
Custom sections, profiles and non-standard shapes subject to product and mill capability.
Customization
Custom dimensions, lengths, surface conditions, end preparations and inspection requirements can be supplied according to project specifications. Final capability is confirmed per enquiry based on grade, size range and applicable standard.
04
Quality
Inspection and documentation procedures are coordinated to meet the requirements of the applicable product standard and the project specification.
- Dimensional inspection Geometry, dimensions and tolerances against the applicable standard
- Visual and surface inspection Surface condition, marking and overall appearance
Documents
- Inspection Report
- Chemical analysis Per heat, against the applicable standard
- Mechanical testing Tensile, yield, elongation and hardness
- Non-destructive testing UT, eddy-current, hydrostatic or other NDT as applicable
- Positive material identification PMI for alloy verification when required
Documents
- Mill Test Certificate (MTC)
- Heat number traceability Heat number carried through MTC and product marking
- Third-party inspection coordination SGS / BV / TÜV on request
Documents
- Third-Party Inspection Report
- EN 10204 documentation 3.1 MTC standard; 3.2 on request
Documents
- EN 10204 3.1 Mill Test Certificate
- EN 10204 3.2 Inspection Certificate
- Certificate of Origin
05
Selection
A well-prepared specification is the most efficient defence against clarification cycles.
- 01 Select material & grade
Choose the material grade according to service conditions, performance requirements and applicable standards.
- 02 Define size & supply condition
Specify the required dimensions, surface condition, heat-treatment condition and delivery requirements.
- 03 Confirm standard & requirements
State the applicable product standard, dimensional standard and governing project specification.
- 04 Define inspection & documentation
Confirm inspection, testing, certification and documentation requirements before order placement.
Example procurement specification
A complete specification suitable for enquiry, covering product, technical requirements, certification and delivery terms.
- Product
- Stainless Steel Wire 304
- Grade
- 304
- Standard
- ASTM A580
- Dimensions
- Ø 1.00 mm × Coil Form (~50 kg/coil); 2B
- Condition
- Solution Annealed; 2B Finish
- Certification
- EN 10204 3.1 Mill Test Certificate
- Quantity
- 20 Metric Tons
- Packaging
- Seaworthy Export Packing
- Incoterm
- CIF Hamburg
06
Logistics
From mill dispatch to destination port, each stage is coordinated with the nominated forwarder and documented against the purchase specification.
-
Packaging
Export-suitable packaging with surface and edge protection.
Bundled, wrapped or crated according to product form and transport mode. Outer surface protected with weather-resistant material; ends and edges shielded against transit damage.
-
Loading
FCL container for standard sizes; break bulk for oversized cargo.
Container loading via nominated forwarder. LCL and dimensions outside container allowance coordinated against the mill dispatch schedule.
-
Documentation
Commercial invoice, packing list and certificate of origin.
Mill documentation travels with the shipment. EN 10204 3.1 / 3.2 certificates and third-party inspection reports provided as per purchase specification.
-
Shipment
Sea freight as standard; alternative routes on request.
FCL / LCL container shipment or break bulk for oversized dimensions. Logistics coordinated through the nominated forwarder.
-
Delivery
FOB · CFR · CIF · FCA · EXW arrangements available.
Incoterm 2020. Port of loading: Shanghai / Ningbo / Shenzhen. Final destination and terms confirmed per enquiry.
07
FAQ
Most enquiries reduce to a small set of recurring technical questions.
01 What is 304 stainless steel wire?
304 stainless wire (1.4301 / SUS304) is an austenitic 18-8 stainless wire offering good corrosion resistance and formability for woven mesh, springs, formed parts and architectural applications.
02 What is stainless wire used for?
Stainless wire is used for woven and welded mesh, conveyor belts, springs, fasteners, kitchen equipment, filters, braiding and architectural meshes.
03 What surface finishes are available?
Bright (cold-drawn), annealed (soft), soap-drawn, oiled and polished finishes are available.
04 What diameters are available?
Common diameters 0.1 mm to 12 mm. Custom diameters can be supplied.
05 Is 304 wire suitable for marine exposure?
For chloride or marine exposure, 316 / 316L wire is preferred due to its molybdenum content and improved pitting resistance.
